DrayTek Vigor2765 Series VDSL Modem Router
Single WAN VDSL2 35b router, with 1 x congurable GbE WAN/LAN port and 3 x GbE LAN ports, supports SPI Firewall, 802.11ax/ac Wi-Fi, 2 x VPN tunnels including 2 x SSL VPN, and SOS/ROC for NBN Internet connection.
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
35b Supervectoring VDSL2/Ethernet Routers for Professionals
Vigor2765ax
802.11ax (WiFi 6, AX3000)
The Vigor2765 Series are 35b Supervectoring VDSL2 modem, firewall and VPN routers. All models have 4 x GbE LAN ports, one of which is switchable to be a backup Ethernet WAN interface. They’re highly configurable with an abundance of features including web content filtering, bandwidth limiting, QoS and lots more. Perfect for professional users who would like to take full control of the network. The series includes models with built-in 802.11ac Wave 2 Wi-Fi (ac/Vac model), 802.11ax Wi-Fi (ax model), and VoIP gateway (Vac model).
Interface
(Vac model)
(ax model)
Performance Comparison: Vigor2765 vs. Vigor2762
NAT throughput (1.5 times faster)
IPSec throughput (2.9 times faster)
SSL-VPN throughput (2 times faster)
Key Features
35b Supervectoring Modem
Integrated VDSL modem with 35b Supervectoring compatibility and VDSL2/ADSL2+ fallback.
DrayDDNS
Free DDNS service to access the router using a fixed hostname of your choice. Learn more
VPN (Virtual Private Network)
Build a secure and private tunnel from the LAN of the Vigor2765 Series to remote offices and teleworkers over the Internet. Learn more
Firewall & Content Filter
Filter web pages by URL keywords or web category to block access to insecure or inappropriate content.
VPN Matcher
Helps routers behind NAT to find each other and establish a LAN-to-LAN VPN. Learn more.
Hotspot Web Portal
Market your business and communicate with guests by offering hospitality Wi-Fi. Learn more
Bandwidth Management
Prevent one device using all the bandwidth by bandwidth limit policy, session limit policy, and QoS settings.
Central AP Management
Use the Vigor2765 Series router as a wireless controller to maintain and monitor the VigorAPs. Learn more
VoIP Friendly (Vac model)
Vigor2765 Series can do port forwarding and reserve bandwidth for VoIP traffic automatically, making VoIP setup effortless. Setup Guide
Mesh (Wireless model only)
Easily link to other VigorAP to expand the wireless network. Learn more.
Hardware Acceleration
Without sacrificing traffic control features such as QoS, Bandwidth Limit, WAN Budget, Traffic Graph and Data Flow Monitor, Hardware Acceleration enhances performance for:
- NAT & routing connections
- QoS
Hardware NAT & Routing
With Hardware Acceleration and Hardware QoS enabled, the router supports up to 4k NAT and routing connections, and firewall performance reaching 940Mbps on either xDSL WAN ( VDSL2 35b/G.fast) or Ethernet WAN.
Single WAN (Ethernet)
1.6x Faster NAT Performance
Hardware QoS
Hardware QoS allows prioritization of applications and services on DrayTek routers, to improve performance of critical applications such as VoIP, conferencing and video streaming, etc. Furthermore, it allows flexible bandwidth allocation to suit business requirements.
Single WAN (xDSL or Ethernet)
1.6x Faster QoS Performance
New OFDMA Feature for 802.11ax (WiFi 6) – Vigor2765ax only
Higher Transmission Efficiency with OFDMA
OFDMA has been used in LTE for many years, and is now available in 802.11ax for multi-user mode.
With legacy OFDM, each frame is transmitted across the entire channel width. When the transmission rate is low, this causes more latency and jitters and lower the overall efficiency.
OFDMA splits a single frame into groups of subcarriers, and each subcarrier can be sent simultaneously. With multiple access mode, it allows multiple users to transmit at the same time thus improving efficiency and enhancing user experiences in high density environments.
OFDM
OFDMA
AP-Assisted Roaming – built-in in selected Wi-Fi Vigor Routers and all Vigor Access Points
Extend Transmission Range
When a Wi-Fi client moves out of its effective transmission range which is defined by the Basic Rate and/or Received Signal Strength threshold, the AP forces the Wi-Fi client to pick up a nearby access point with stronger signals thereby extending the range.
Improve Data Rates
When the “Minimum RSSI with Adjacent AP” option is set, APs or routers on the same local subnet will exchange client information with each other and switch to the AP or router that has the strongest signal, ensuring that data rates can be as good as possible.
Better User Experience
Instead of ineffective transmission with low basic rates or RSSI, the better links provide better user experience while saving the airtime.
No Controller Required
Assisted Roaming is a built-in feature in all Vigor Access Points and a number of Wi-Fi routers; it saves the need for an ad-hoc wireless controller and is an ideal solution for simple network deployments.
Hotspot Web Portal
Market your business while offering free Wi-Fi
Wi-Fi Marketing
Redirect hotspot guests to the company homepage, online surveys, or display a promotion message.
Grow Customer Mailing List
Require guests to leave contact info or social media accounts before they can use the Internet services.
Various Authentication Types
Various login methods are supported to meet your business needs, including Facebook Login, Google Login, SMS PIN, and RADIUS.
3rd-Party Service Compliant
Supports external captive portal authentication so you can keep using the Wi-Fi marketing solution you prefer.
Data Quota Management
Bandwidth management is integrated into the Hotspot features to control the bandwidth and session usage of the Hotspot guests.
LAN Management
A Network Management platform for Vigor devices to manage devices on the network
Automatic Device Discovery
Connect a Vigor AP to the LAN side, and the Vigor router will discover it automatically.
Provisioning
Basic settings of the managed Vigor AP will be configured by the router automatically.
Monitoring
The status of the connected devices, such as Vigor APs, will be monitored by the Vigor Router.
System Maintenance
Tasks such as factory reset, backup and restore of configuration settings, or remote reboot can be performed from the Vigor routers, without needing to log in to the devices’ management pages.
All-in-One Management
Mesh Management
Up to 7 APs
- DrayTek Wireless app-support
- Discovery
- Auto-Provisioning
- Monitoring
- Centralized Hierarchy View
VigorAP-based APM
Up to 2 APs
- Auto-Discovery
- Auto-Provisioning
- Monitoring
- Centralized View
- Alarm
- Reboot VigorAP Remotely
- Wi-Fi Client Load Balancing
Software Management
VigorACS 2
- Provisioning
- Monitoring
- Centralised Hierarchy View
- Alarm
- Reboot Vigor Devices Remotely
- Scheduled Maintenance
- Report
VigorACS 3
- Zero Touch Deployment & Provisioning
- Auto VPN
- Interface Quality & SLA
- VoIP Optimization & Monitoring
- Application Visibility
- Application Based SD-WAN Policy
- Customized Hotspot Page with Multilingual
- Hotspot Clients Analytics
- ACS Server Load Balancing / Failover
In-the-Box
Vigor2765/ac/Vac
Vigor2765ax
(ax model)
2 x Wireless Antennas
(ac/Vac models)
RJ-45 Cable
(Ethernet)
RJ-45 to RJ-45 Cable
(Annex B)
RJ-11 to RJ-45 Cable (Annex B)
RJ-11 to RJ-11 Cable (Annex A)
Power Adaptor
Quick Start Guide
- plications activated.
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Model | Vigor2765, Vigor2765ac, Vigor2765ax, Vigor2765Vac |
Models
| odel | Vigor2765 | Vigor2765ax | Vigor2765ac | Vigor2765Vac |
|---|---|---|---|---|
| Product |  |
 |
 |
 |
| VDSL2 35b/ ADSL2/2+ |
Yes
|
Yes
|
Yes
|
Yes
|
| Selectable Gigabit WAN/LAN |
Yes
|
Yes
|
Yes
|
Yes
|
| 4G LTE/3G | 2 x USB 2.0 | 2 x USB 2.0 | 2 x USB 2.0 | 2 x USB 2.0 |
| Wireless WAN |
No
|
No
|
No
|
No
|
| Gigabit LAN | 3 | 3 | 3 | 3 |
| VPN Tunnels | 2 | 2 | 2 | 2 |
| Wireless LAN |
No
|
WiFi 6, AX3000 | WiFi 5, AC1300 | WiFi 5, AC1300 |
| Wi-Fi Antenna |
No
|
2.5dBi for 5GHz 2.7dBi for 2.4GHz |
4dBi for 5GHz 2dBi for 2.4GHz |
4dBi for 5GHz 2dBi for 2.4GHz |
| VoIP (2xFXS) |
No
|
No
|
No
|
Yes
|
Specifications
| Interface | |
|---|---|
| Fixed WAN Port | 1 x RJ-11 for VDSL2 35b or ADSL2/2+ |
| LAN/WAN Switchable Port | 1 x 10/100/1000Base-T, RJ-45 (P4) |
| Fixed LAN Port | 3 x 10/100/1000Base-T, RJ-45 |
| USB Port | 2 x USB 2.0 for 3G/4G LTE USB modem, storage, printer or thermometer |
| Wi-Fi Antenna | 2 x External Dipole, Gain: 4 dBi for 5GHz, 2 dBi for 2.4GHz (ac/Vac model) 2x External Dipole, Gain: 2.5 dBi for 5GHz, 2.7 dBi for 2.4GHz (ax model) |
| 2.4G WLAN | 802.11n 2×2 MIMO 400Mbps (ac/Vac model) 802.11ax 2×2 MIMO, up to 574Mbps Link Rate (ax model) |
| 5G WLAN | 802.11ac Wave 2 2×2 MU-MIMO 867Mbps (ac/Vac model) 802.11ax 2×2 MU-MIMO, up to 2402Mbps Link Rate (ax model) |
| FXS RJ-11 | 2 (Vac model) |
| Performance | |
|---|---|
| Max. Throughput on VDSL | 300 Mbps |
| NAT Throughput | 600 Mbps |
| NAT Throughput w/ Hardware Acceleration | 940 Mbps |
| IPsec VPN Performance | 150 Mbps (AES 256 bits) |
| SSL VPN Performance | 100 Mbps |
| Max. Number of NAT Sessions | 50,000 |
| Max. Concurrent VPN Tunnels (including SSL VPN) | 2 |
| VDSL/ADSL | |
|---|---|
| VDSL Standards | ITU-T G.993.2 Annex A/B/M/Q (up to Profile 35b but excluding 30a) T1.424 ITU-T G.993.5 (Vectoring) |
| VDSL2 Profile | 8a, 8b, 8c, 8d, 12a, 12b, 17a, 35b (not G.Fast) |
| ADSL Standards | ITU-T G.992.1 (G.dmt), ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.5 (ADSL2+) (G.adslplus), T1.413 Issue 2 |
| Other Standards | ITU-T G.994.1 (G.hs), ITU-T G.997.1 (G.ploam), ITU-T G.998.4 (Retransmission) |
| Band Plan | 998, 997 |
| Internet Connection | |
|---|---|
| IPv4 | PPPoE, PPPoA, DHCP, Static IP, MPoA, PPTP/L2TP |
| IPv6 | PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
| Multi-VLAN/PVC | |
| WAN Failover | |
| Connection Detection | ARP, Strict ARP, Ping |
| WAN Data Budget | |
| Dynamic DNS | |
| DrayDDNS | |
| LAN Management | |
|---|---|
| VLAN | 802.1q Tag-based, Port-based |
| Max. Number of VLAN | 8 |
| Number of LAN Subnet | 4 |
| DHCP Server | Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
| Wired 802.1x Authentication | |
| Port Mirroring | |
| Local DNS Server | |
| Conditional DNS Forwarding | |
| Hotspot Web Portal | |
| Hotspot Authentication | Click-Through, Social Login, SMS PIN, Mail PIN, RADIUS, External Portal Server |
| Networking | |
|---|---|
| Routing | IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2 |
| Policy-based Routing | Protocol, IP Address, Port, Domain, Country |
| DNS Security (DNSSEC) | |
| IGMP | IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave |
| SMB File Sharing | (Requires external storage) |
| VPN | |
|---|---|
| LAN-to-LAN | |
| Teleworker-to-LAN | |
| Protocols | PPTP, L2TP, IPsec, L2TP over IPsec, SSL, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN |
| User Authentication | Local, RADIUS, mOTP |
| IKE Authentication | Pre-Shared Key, X.509 |
| IPsec Authentication | SHA1, SHA256, MD5 |
| Encryption | MPPE, DES, 3DES, AES128, AES192, AES256 |
| Single-Armed VPN | |
| NAT-Traversal (NAT-T) | |
| DrayTek VPN Matcher | |
| Firewall & Content Filtering | |
|---|---|
| NAT | Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
| ALG (Application Layer Gateway) | SIP, RTSP, FTP, H.323 |
| VPN Pass-Through | PPTP, L2TP, IPsec |
| IP-based Firewall Policy | |
| Content Filtering | Application, URL, DNS Keyword, Web Features, Web Category (subscription required) |
| DoS Attack Defence | |
| Spoofing Defense | |
| Bandwidth Management | |
|---|---|
| IP-based Bandwidth Limit | |
| IP-based Session Limit | |
| QoS (Quality of Service) | TOS, DSCP, 802.1p, IP Address, Port, Application |
| VoIP Prioritization | |
| APP QoS | |
| Wireless LAN (ac/Vac/ax model) | |
|---|---|
| WiFi 6 | (ax model) |
| Number of SSID | 4 per radio band |
| Security Mode | OWE, WEP, WPA, WPA2, Mixed(WPA+WPA2), WPA3 |
| Authentication | Pre-Shared Key, 802.1x |
| OFDMA | (ax model) |
| WPS | PIN, PBC |
| WDS Repeater | (5GHz only) |
| Access Control | Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling |
| AirTime Fairness | |
| Band Steering | (ac/Vac model) |
| MU-MIMO | 5GHz Only (dual-band model) |
| WMM | |
| VoIP Gateway (Vac model) | |
|---|---|
| Protocol | SIP, RTP/RTCP, ZRTP |
| SIP Registrars | 6 |
| Dial Plan | Phone Book, Digit Map, Call Barring, Regional |
| Call Features | Call Waiting, Call Transfer, Scheduled DND, Hotline |
| Voice Codec | G.711 A/u law, G.726, G.729 A/B |
| Caller ID | FSK_ETSI, FSK_BELLCORE, DTMF |
| Management | |
|---|---|
| Local Service | HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069 |
| Config File Export & Import | |
| Config File Compatibility | Vigor2760 Series, Vigor2762 Series, Vigor2763 Series, Vigor2765 Series, Vigor2766 Series |
| Firmware Upgrade | TFTP, HTTP, TR-069 |
| 2-Level Administration Privilege | |
| Access Control | Access List, Brute Force Protection |
| Notification Alert | SMS, E-mail |
| Netflow | (v5, v9, IPFIX) |
| SNMP | v1, v2c, v3 |
| Syslog | |
| Managed by VigorACS | |
| Central AP Management | 2 VigorAPs |
| Mesh Network | 7 VigorAPs (ac/Vac model) |
| Physical | |
|---|---|
| Power Supply | DC 12V @ 1.5A-2A |
| Max. Power Consumption | 21.6 watts (Vac model) |
| Dimension | 207mm x 131mm x 42mm 194mm x 155mm x 50mm (ax model) |
| Weight | 500g (ac model) |
| Operating Temperature | 0 to 45°C |
| Storage Temperature | -25 to 70°C |
| Operating Humidity (non-condensing) | 10 to 90% |
| Certificate |    |
Note :
- All specifications are subject to change without notice.
- The throughput figures are maximum, based on DrayTek internal testing with optimal conditions. The actual performance may vary depending on the different network conditions and applications activated.
