Description
| Camera | |
|---|---|
| Image Sensor: | 1/1.8″ Progressive Scan CMOS |
| Min. Illumination: | Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter time: | 1 s to 1/100,000 s |
| Slow shutter: | Yes |
| Lens: | 2.8 to 12 mm, horizontal FOV 102° to 38°, vertical FOV 53.0° to 21.2°, diagonal FOV 122.2° to 45° |
| Adjustment Range: | Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Day& Night: | IR Cut Filter |
| Wide Dynamic Range: | 140dB |
| Digital noise reduction: | 3D DNR |
| Compression Standard | |
| Audio Compression: | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio bit rate: | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/128-768Kbps(PCM) |
| Image | |
| Max. Image Resolution: | 2560 × 1440 |
| Sub Stream: | 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480) |
| Third Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Image Enhancement: | BLC, HLC, Defog, EIS |
| Target Cropping: | Yes |
| Picture Overlay: | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Day/Night Switch: | Auto/Schedule/Day/Night/Triggered by Alarm In |
| Network | |
| Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Interface | |
| Communication Interface: | 1 RJ45 10M/100M/1000M Ethernet port |
| Alarm: | 1-ch input, 1-ch output (up to 24 VDC 1A or 110 VAC 500 mA) |
| Reset Button: | Yes |
| Smart Feature-set | |
| Behaviour Analysis: | Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal |
| Exception Detections: | Scene change detection, Sudden audio increase/decrease detection, Audio loss detection, Defocus detection |
| Statistics: | Object Counting (Entrance and Exit object number is accounted and showed on screen in real time) |
| General | |
| Operation Condition: | -IZS: -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) -IZHS: -40 °C to 60 °C (-40 °F to 140 °F), humidity 95% or less (non-condensing) |
| Power Consumption: | -IZS: 12 VDC ± 20%: 1.2 A, max. 12 W, PoE (802.3at, class 3): 42.5 V to 57 V, 0.3 A to 0.2 A -IZHS: 12 VDC ± 20%: 1.4 A, max. 17 W, PoE (802.3at, class 3): 42.5 V to 57 V, 0. 4 A to 0.3 A |
| Dimensions: | Camera: Φ162 × 140.3 mm (Φ6.4″ × 5.5″) With package: 251 × 215 × 189 mm (9.9″ × 8.5″ × 7.4″) |
| Weight: | Camera: 1450 g (3.20 lb.) With package: 1950 g (4.30 lb.) |
