DrayTek Vigor2962 Series Broadband Router

$815

6 products sold in last 19 hours
Selling fast! Over 8 people have in their cart

High Performance 2.5GbE Multi-WAN Broadband VPN Routers with GbE PoE LAN Ports

Multi-WAN broadband routers with 1 x 2.5GbE WAN/LAN port, 1 x 1GbE combo SFP/Ethernet WAN/LAN port, 2 x GbE WAN/LAN ports, 2 x fixed GbE LAN ports, 4 x Gigabit PoE LAN ports with a total power budget of 65 Watts (Vigor2962P), SPI Firewall, and 200 x VPN tunnels including 50 x SSL-VPN tunnels

20 people are viewing this right now
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout
SKU: Vigor2962 Category: Brand:

  • NBN (National Broadband Network – Australia) Ready to connect to NTD (Network Termination Device)

  • 2 x GbE configurable LAN/WAN ports *

  • 1 x 2.5GbE configurable LAN/WAN port *

  • 1 x 1GbE combo SFP Fibre / Ethernet configurable WAN/LAN port *

  • Multi-WAN Load Balancing & Failover

  • Up to 5 x Gigabit LAN ports with 300,000 NAT sessions

  • 2.2 Gbps NAT throughput

  • 4 x Gigabit PoE LAN ports with a total power budget of 65 Watts (Vigor2962P) **

  • 2 x USB ports for USB disk storage

  • Object-based SPI Firewall, Content Security Management (CSM) and QoS

  • 200 x VPN tunnels (including 50 x OpenVPN/ SSL-VPN tunnels) with comprehensive secure protocols
  • Up to 1 Gbps site-to-site IPsec VPN throughput
  • Fast VPN throughput, VPN Load Balancing, Failover, and backup for site-to-site applications

  • 20 x VLANs and LAN subnets for secure and efficient workgroup management

  • IPv6 & IPv4

  • High-Availability (with CARP) ensuring 24/7 system uptime

  • Bandwidth management

  • Supports VigorACS 2 and VigorACS 3 Central Management Software for remote management

  • SD WAN capability when used with VigorACS 3

  • Central AP Management for up to 50 Vigor Access Points Learn more

  • Central Switch Management for up to 30 VigorSwitches Learn more

  • Rack-mountable

  • 2 years back to base warranty

* Switchable WAN/LAN Port, up to 2 simultaneous WANs
** P1/P4/P5/P6: PoE-Out ports (Vigor2962P)

High Performance 2.5GbE VPN Security Routers

2962 port H1125

Vigor2962 series are high performance and dynamic firewall routers with configurable GbE WAN/LAN ports. From the supported 2.5GbE port, 1GbE SFP port, and 2 x 1GbE ports, users can set 2 WANs for Load Balancing/Failover purposes and receive a maximum of 2.2 Gbps NAT throughput.

The Vigor2962P router is a PoE capable router with 4 x GbE PoE LAN ports providing a total of 65 Watts of power, and is an ideal solution where PoE devices such as Wireless Access Points or IP cameras are deployed on the network.

Up to 2 WANs

Including 1 x 2.5GbE WAN port, and 1 x 1GbE/SFP Combo or Ethernet WAN port

200 x VPN tunnels

IPsec VPN throughput up to 1 Gbps

50 x SSL-VPN tunnels

Throughput up to 800 Mbps

2.2 Gbps

Max. NAT Throughput
2962P interface v2
  1. Power Input
  2. Power On/Off Switch
  3. Reset Button
  1. LED Indicator
  2. 1 x 2.5GbE configurable LAN/WAN port *
  3. 1 x 1GbE combo SFP Fibre / Ethernet configurable WAN/LAN port *
  1. 2 x Gigabit configurable LAN/WAN ports *
  2. Fixed LAN Port: 2 x GbE RJ-45
  3. 1 x USB 2.0 & 1 x USB 3.0 for USB disk storage

* Switchable WAN/LAN Port, up to 2 simultaneous WANs
** P1/P4/P5/P6: PoE-Out ports (Vigor2962P)

Performance Comparison: Vigor2962 vs. Vigor2960

Vigor2962 users can choose a single WAN (1 x 2.5GbE) or dual WAN (2 x 1GbE) for Load Balancing and Failover, for up to 2.2Gbps of high NAT throughput. The PoE model (Vigor2962P) supports 4 x PoE ports and provides a total power budget of 65Watts.

NAT throughput (2.4 times faster)

2.2 Gbps

Vigor2962

900 Mbps

Vigor2960

IPSec throughput (1.7 times faster)

1 Gbps

Vigor2962

600 Mbps

Vigor2960

SSL-VPN throughput (2.3 times faster)

800 Mbps

Vigor2962

300 Mbps

Vigor2960

Key Features

Load Balancing

Maximise throughput and reliability by using multiple Internet connections. Learn more

Bandwidth Management

Prevent one device using all the bandwidth with bandwidth limit policy, session limit policy, and QoS settings.

VPN (Virtual Private Network)

Build a secure and private tunnel from the LAN of Vigor2962 to the remote offices and teleworkers over the Internet. Learn more

Firewall & Content Filter

Filter web pages by URL keywords or web category to block access to insecure or inappropriate content.

SSL VPN

The VPN works through firewalls providing secure remote access to any network environment. Learn more

DrayDDNS

Free DDNS service to access the router using a fixed hostname of your choice. Learn more

VPN Matcher

Helps routers behind NAT to find each other and establish a LAN-to-LAN VPN. Learn more

Central AP Management

Use the Vigor2962 Series router as a wireless controller to maintain and monitor VigorAPs. Learn more

PPPoE Server

Use Point-to-Point connection on LAN to keep track of individual user’s traffic. Setup Guide

Central Switch Management

Set up VLANs easily from the router and get a centralised hierarchy view of the switches. Learn more

Hotspot Web Portal

Market your business and communicate with guests by offering hospitality Wi-Fi. Learn more

Flexible WAN/LAN Ports

Vigor2962 series routers feature four configurable WAN/LAN ports, including one 2.5GbE port, one SFP/GbE combo port, and two GbE ports. A maximum of two of the four ports can be used as WAN ports concurrently. Dual WAN for Load Balancing/Failover improves Internet resilience of your business networks.

2962 switchable ports

Hardware Redundancy with High Availability

To avoid a single point of failure, Vigor2962 supports Hot-Standby and Active-Standby modes for Hardware Redundancy. Upon detecting a hardware failure, the Failover function will switch over to the standby router within 1 second.

PoE (Vigor2962P)

With a total power budget of 65W, each IEEE802.3at PoE port provides up to 32W power to devices such as IP camera, Wireless AP, IP phone, etc.

VPN Hub with High Dialing Speed

Up to 200 concurrent VPN tunnels for branches (LAN-to-LAN) and remote workers (remote dial-in) are supported.

Vigor2962P – PoE (Power over Ethernet Function)

Vigor2962P PoE

Hotspot Web Portal

Market your business while offering free Wi-Fi

Wi-Fi Marketing

Redirect hotspot guests to the company homepage, online surveys, or display a promotion message.

Grow Customer Mailing List

Require guests to leave contact info or social media accounts before they can use the Internet services.

vigor hotspot portal

Various Authentication Types

A variety of login methods are supported to meet your business needs, including Facebook Login, Google Login, SMS PIN, Voucher PIN, and RADIUS.

3rd-Party Service Compliant

Supports external captive portal authentication so you can keep using the Wi-Fi marketing solution you prefer.

Data Quota Management

Bandwidth management is integrated into the Hotspot features to control the bandwidth and session usage of the Hotspot guests.

Management Solution

Software Management

VigorACS 3

software management acs3

  • Zero Touch Deployment & Provisioning
  • Auto VPN
  • Interface Quality & SLA
  • VoIP Optimization & Monitoring
  • Application Visibility
  • Application Based SD-WAN Policy
  • Customized Hotspot Page with Multilingual
  • Hotspot Clients Analytics
  • ACS Server Load Balancing / Failover
All-in-One Management

Vigor Router SWM

vigor router swm

  • Auto-Discovery
  • Provisioning
  • Monitoring
  • Centralized Hierarchy View
  • Reboot PoE Devices Remotely
  • Quick VLAN Configuration

VigorAP-based APM

vigor router apm

  • Auto-Discovery
  • Auto-Provisioning
  • Monitoring
  • Centralized View
  • Alarm
  • Reboot VigorAP Remotely
  • Wi-Fi Client Load Balancing

In-the-Box

Vigor2962 Front

Vigor2962/Vigor2962P

rack mount kit 3900

Rack Mount Kit
(brackets)

ethernet cable

RJ-45 Cable
(Ethernet)

power core AU

Power Adaptor

quick start guide

Quick Start Guide

Note :

The throughput figures are maximum, based on DrayTek internal testing with optimal conditions. The actual performance may vary depending on the different network conditions and applications activated.

Model

Vigor2962, Vigor2962P

Models
Model Vigor2962 Vigor2962P
Configurable WAN/LAN port 1 x 2.5GbE (RJ-45)
1 x 1GbE SFP/GbE Combo
2 x GbE (RJ-45)		 1 1 x PoE 2.5GbE (RJ-45)
2 1 x 1GbE SFP/GbE Combo
3 1 x GbE (RJ-45)
4 1 x PoE GbE (RJ-45)
Fixed LAN Port 2 x GbE (RJ-45) 5 2 x PoE GbE (RJ-45)
PoE Budget
No
 65W
USB Port 1 x USB 2.0 + 1 x USB 3.0 6 1 x USB 2.0 + 1 x USB 3.0
NAT Throughput 2.2 Gbps
VPN 200 (IPsec VPN throughput up to 1 Gbps))
NAT sessions 300,000 NAT sessions



Specifications

Interface
LAN/WAN Configurable Port 1x 2.5G Ethernet, RJ-45 (PoE capable port for P model)
1x GbE/SFP Combo
2x GbE, RJ-45 (PoE capable port(P4) for P model)
* up to 2 simultaneous WANs
Fixed LAN Port 2x GbE, RJ-45 (PoE capable ports for P model)
USB Port 1x USB 2.0 + 1x USB 3.0 for USB disk storage (since f/w v3.9.4)
Performance
NAT Throughput w/ Hardware Acceleration 2.2 Gbps
IPsec VPN Performance 1 Gbps (AES 256 bits)
SSL VPN Performance 800 Mbps
Max. Number of NAT Sessions 300,000 NAT sessions (since f/w v3.9.6)
Max. Concurrent VPN Tunnels 200
Max. Concurrent OpenVPN/ SSL-VPN 50
PoE (P model)
PoE Capable Ports 4 (P1/P4/P5/P6)
PoE Standards PoE/PoE+ (802.3af/802.3at)
Power Budget 65 watts
PD Device Check Yes
Internet Connection
IPv4 PPPoE, DHCP, Static IP
IPv6 PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel
802.1p/q Multi-VLAN Tagging Yes
Multi-VLAN/PVC Yes
Load Balancing IP-based, Session-based
WAN Active on Demand Link Failure, Traffic Threshold
Connection Detection ARP, Ping, Strict ARP
WAN Data Budget  (since f/w v3.9.6)
Dynamic DNS Yes
DrayDDNS Yes
LAN Management
VLAN 802.1q Tag-based, Port-based
Max. Number of VLAN 20
Number of LAN Subnet 20
DHCP Server Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC
LAN IP Alias Yes
Wired 802.1x Authentication Yes
Port Mirroring Yes
Local DNS Server Yes
Conditional DNS Forwarding Yes
Hotspot Web Portal Yes
Hotspot Authentication Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server
Networking
Routing IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, OSPF, BGP (IPv4)
Policy-based Routing Protocol, IP Address, Port, Domain, Country
High Availability Yes
DNS Security (DNSSEC) Yes
IGMP IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave
Local RADIUS server Yes
VPN
LAN-to-LAN Yes
Teleworker-to-LAN Yes
Protocols PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec-XAuth, OpenVPN (Host to LAN)
User Authentication Local, RADIUS, LDAP, TACACS+, mOTP
IKE Authentication Pre-Shared Key, X.509
IPsec Authentication SHA-1, SHA-256, MD5
Encryption MPPE, DES, 3DES, AES
VPN Trunk (Redundancy) Load Balancing, Failover
Single-Armed VPN Yes
NAT-Traversal (NAT-T) Yes
DrayTek VPN Matcher Yes
Firewall & Content Filtering
NAT Port Redirection, Open Ports, Port Triggering, DMZ Host
ALG (Application Layer Gateway) SIP, RTSP, FTP, H.323
VPN Pass-Through PPTP, L2TP, IPsec
IP-based Firewall Policy Yes
Content Filtering Application, URL, DNS Keyword, Web Features, Web Category* (* subscription required)
DoS Attack Defense Yes
Spoofing Defense Yes
Bandwidth Management
IP-based Bandwidth Limit Yes
IP-based Session Limit Yes
QoS (Quality of Service) TOS, DSCP, 802.1p, IP Address, Service Type
VoIP Prioritisation Yes
Management
Local Service HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069
Config File Export & Import Yes
Firmware Upgrade TFTP, HTTP, TR-069
2-Level Administration Privilege Yes
Access Control Access List, Brute Force Protection
Notification Alert SMS, E-mail
SNMP v1, v2c, v3
Syslog Yes
Managed by VigorACS Yes
Central AP Management 50 VigorAPs
Central Switch Management 30 VigorSwitches
Physical
Rack Mountable  Mouting Kit Included
Power Supply AC 100-240V @ 1A
Max. Power Consumption 100 watts (P model)
Dimension 273mm x 171mm x 45mm
Weight 1.53 kg (P model)
Operating Temperature 0 to 45°C
Storage Temperature -25 to 70°C
Operating Humidity (non-condensing) 10 to 90%
Certificate

Note :

  • All specifications are subject to change without notice.
  • The throughput figures are maximum, based on DrayTek internal testing with optimal conditions. The actual performance may vary depending on the different network conditions and applications activated.
